6642

GENERAL SPECIFICATION • Torque: 1.50 Nm (1.10 Ft.lb) max. applied to nut • Panel thickness: 4.5 mm (.177) max. ENVIRONMENTAL SPECIFICATIONS • Operating temperature: -20 °C to +55 °C (-20 °F to 131 °F) ELECTRICAL SPECIFICATIONS • Max. current/voltage rating with resistive load: 10 A 30 VDC • Decrease by 50 % for inductive load • Initial contact resistance: 10 m? max. • Insulation resistance: 1,000 M? min. at 500 VDC • Dielectric strength: 2,500 Vrms 50 Hz min. between terminals 2,500 Vrms 50 Hz min. between terminals and frame • Electrical life: 10,000 cycles at full load MATERIALS • Case: melamine/polyester • Actuator: brass, nickel plated • Bushing: brass, nickel plated • Contacts: silver
