GENERAL SPECIFICATION
• Travel : 0,67 mm (.026)
ENVIRONMENTAL SPECIFICATIONS
• Operating temperature : -40°C to +100°C
• Storage temperature : -40°C to +125°C
ELECTRICAL SPECIFICATIONS
• Max. current/voltage rating :
- switching : 100mA 24VDC
- non-switching : 100mA 48VDC
• Contact resistance :
- initial : 30 m? max.
- after 2.000 cycles : 100 m? max.
• Insulation resistance : 1.000 M? min. at 500VDC
• Dielectric strength : 500 VAC min.
• Electrical life : 2.000 cycles
MATERIALS
• Case and actuator : UL 94-V0 thermoplastic
• Stationary contact : bronze, gold plated over nickel barrier
• Moving contact : beryllium copper, gold plated
• Terminals : tin plated over nickel barrier
• Protection tape : polyimide
