QRM85BXXY28E

Print this page

Description

Brand APEM
Product CodeQRM85BXXY28E
Stock Status154
Stock154

APEM QRM Series 8mm Yellow 28V LED

The QRM8 Series is a range of Ø8 mm diameter indicators which are rear mounted,
epoxy sealed and designed to be offered to the back of the panel for assembly.
They are available in bi-colored and tri-colored LEDs.
MAIN FEATURES
IP67 sealed to EN60529
Rear end epoxy sealed
Black chrome or anodized finish

QRM85BXXY28E 3D Drawing

QRM Series Datasheet

SERIES

157.37 €

Piece	Add to Cart
Birim Fiyat
Toplam Fiyat

Piece	Unit price	Total
25	17.49 €	437.25 €
100	13.67 €	1,367.00 €
500	12.02 €	6,010.00 €
1000	10.12 €	10,120.00 €

Property Name	Property Value
SERIES	QRM
MOUNTING HOLE	Ø8 mm
TERMINALS	Wires
BEZEL FINISH	Black Chrome
TYPE OF ILLUMINATION	Fixed Light
LED COLOR	Yellow
VOLTAGE	28 VDC
SEALING	IP67 (Standard)

We'll Call You

Tags: apem qrm 8mm yellow led 28v led QRM85BXXY28E

Description

GENERAL SPECIFICATION

• Max Reverse Voltage: 5V

• Viewing Angle: 60°

• Life Expectancy: 100,000 hours

• Max panel thickness: 3.5mm

• Torque: 60cNm

ENVIRONMENTAL SPECIFICATIONS

• Operating Temperature Range: –40°C to +85°C

• Storage Temperature Range: –55°C to +100°C

• IP67 sealed (EN60529)

ELECTRICAL SPECIFICATIONS

• 02 (No Resistor) 1.8 to 3.8VDC 20mA max

• 6VDC 5.4 to 6.6VDC 20mA

• 12VDC 10.8 to 13.2VDC 20mA

• 24VDC 21.6 to 26.4VDC 20mA

• 28VDC 25.2 to 30.8VDC 20mA

MATERIALS

• Body: Black chrome plated brass or anodized finish

• Nut: Black chrome plated brass or anodized finish

• Panel seal: Nitrile O-ring

• Lock washer: Spring steel

• Terminal seal: Epoxy

• Wires: 24AWG to UL1061

APPROVALS

UL
